Main Specifications | |
Transformer type | dry type |
Frequency | 50/ 60 Hz |
Rated capacity | Up to 8000kVA |
Rated voltage | Up to 11kV |
Insulation class | H(180℃) , C (220℃) |
Cooling mode |
ANAN,GNAN |
Explosion-proof type | ExdIMb |
lightning impulse withstand voltage(Peak) | 75kv, 60kv |
Connection code | Yd, Dyn, Yyn etc. |
Enclosure class | IP54 IP55 |
Zone | Zone 1, Zone 2 |
Altitude | Max 2300M |
WHY Choose VERELEN
For each transformer are prepared and issued a test report, in accordance with IEC 60079. except for routine tests, we also offer type tests and specialised tests to meet all customer requirements. We make what matters work for our customers in a safe and reliable way.
Varelen has launched online FAT plan for customers. Our factory can make acceptance testing ( either witnessed and on-line) in order to show all technical and quality requirements have been done before shipment.
Routine Test
Type Test
Special Test
